Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Cables, Wires>Multiple Conductor Cables
Mfr Alpha Wire
Series Xtra-Guard® 1
Package Spool
Cable Type Multi-Conductor
Number of Conductors 2
Wire Gauge 20 AWG
Conductor Strand 7/28
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter 0.212" (5.38mm)
Shield Type Foil
Length 1000.0' (304.8m)
Jacket Color Slate
Ratings ISO 10993, UL Style 2464
Features Biological Compatibility, Drain Wire, Rip Cord
Voltage 300 V
Temperature Range - Operating -30°C ~ 105°C
Usage Communication, Control
Jacket (Insulation) Thickness 0.0320" (0.813mm)
Conductor Insulation Poly-Vinyl Chloride (PVC)
Shield Material Aluminum
Shield Coverage 100%
Base Product Number 5462C
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8544.49.3080
Other Names 5462CSL001-ND,5462CSL001-1000,5462C SL001-ND,5462CSL001
Standard Package 1
Win Source Part Number 1017824-5462C SL001
Ultra Librarian 3D Model Ultra Librarian 5462C SL001 CAD Model

Description

The 5462C SL001 is a multi-conductor cable that is perfect for communication and control usage manufactured by Alpha Wire.

  • Wire Gauge: 20 AWG
  • Length: 1000.0' (304.8m)
  • Shielding: aluminum
  • Shield Type: foil
  • Shield Coverage: 100%
  • Cable Jacket Insulation: Poly-Vinyl Chloride (PVC)
  • Jacket Thickness: 0.0320" (0.813mm)
  • Jacket Color: Slate
  • Temperature Range: -30°C ~ 105°C
  • ISO Rating: ISO 10993 rated
  • UL Certified: UL Style 2464 certified
