ACS758KCB-150U-PFF-T Real Image ACS758KCB-150U-PFF-T real image23918
Same model may have multiple batches, images only for reference.
ACS758KCB-150U-PFF-T Real Image ACS758KCB-150U-PFF-T real image23918
ACS758KCB-150U-PFF-T Real Image ACS758KCB-150U-PFF-T real image23918
Same model may have multiple batches, images only for reference.

ACS758KCB-150U-PFF-T

Part No ACS758KCB-150U-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 150A 5-CB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Series Automotive, AEC-Q100
Package Tube
Product Status Active
For Measuring DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 150A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 26.7mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±1.6%
Voltage - Supply 3V ~ 5.5V
Response Time 4µs
Current - Supply (Max) 13.5mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Unidirectional
Mounting Type Through Hole
Package / Case 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Base Product Number ACS758
Standard Package 34 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 847569-ACS758KCB-150U-PFF-T
Ultra Librarian 3D Model Ultra Librarian ACS758KCB-150U-PFF-T CAD Model

Description

The ACS758KCB-150U-PFF-T is a current sensor designed for automotive applications from Allegro MicroSystems, LLC.

  • Application: Automotive
  • Sensor Type: Hall Effect
  • Configuration: Open-Loop
  • DC Current: Up to 150A
  • Sensitivity: 26.7mV/A
  • Polarization: Unidirectional
  • Voltage Range: 3V to 5.5V
  • Supply Current: 13.5mA (max)
  • Response Time: 4µs
  • Package Type: 5-CB Formed Leads, PFF
  • Mounting: Through Hole
  • Operating Temperature: -40°C to 125°C
  • Status: Active
