ACS723LLCTR-40AU-T Real Image ACS723LLCTR-40AU-T real image21484
Same model may have multiple batches, images only for reference.
ACS723LLCTR-40AU-T Real Image ACS723LLCTR-40AU-T real image21484
ACS723LLCTR-40AU-T Real Image ACS723LLCTR-40AU-T real image21484
Same model may have multiple batches, images only for reference.

ACS723LLCTR-40AU-T

Part No ACS723LLCTR-40AU-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 40A DC
Datasheet
ACS723LLCTR-40AU-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 40A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 100mV/A
Frequency DC ~ 80kHz
Linearity ±1%
Accuracy ±3%
Operating Supply Voltage 5V
Response Time 5μs
Maximum Supply Current 14mA
Operating Temperature Range -40°C ~ 150°C
Polarization Unidirectional
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 766985-ACS723LLCTR-40AU-T
Popularity Medium
Supply and Demand Status Balance
Family Name ACS723
Introduction Date July 31, 2014
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACS723LLCTR-40AU-T CAD Model

Description

The ACS723LLCTR-40AU-T is a current sensor IC designed for DC current sensing applications.

  • Current: 40A
  • Sensitivity: 100mV/A
  • Output: Ratiometric and voltage-based
  • Response Time: 5μs
  • Frequency Range: DC to 80kHz
  • Operating Temperature: -40°C to 150°C
  • Package: 8-SOIC
  • Linearity: ±1%
  • Accuracy: ±3%
