ACS718KMATR-10B-T Real Image ACS718KMATR-10B-T Real Image
Same model may have multiple batches, images only for reference.
ACS718KMATR-10B-T Real Image ACS718KMATR-10B-T Real Image
ACS718KMATR-10B-T Real Image ACS718KMATR-10B-T Real Image
Same model may have multiple batches, images only for reference.

ACS718KMATR-10B-T

Part No ACS718KMATR-10B-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 10A AC/DC
Datasheet
ACS718KMATR-10B-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 10A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 200mv/A
Frequency 40kHz
Linearity ±1%
Accuracy ±2%
Operating Supply Voltage 5V
Response Time 13μs
Maximum Supply Current 9mA
Operating Temperature Range -40°C ~ 125°C
Polarization Bidirectional
Mounting SMD
Package 16-SOIC (0.295", 7.50mm Width)
Win Source Part Number 766981-ACS718KMATR-10B-T
Popularity Medium
Supply and Demand Status Limited
Family Name ACS718
Introduction Date January 28, 2015
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACS718KMATR-10B-T CAD Model

Description

The ACS718KMATR-10B-T is a Hall Effect sensor that can measure both AC and DC current.

  • Sensitivity: 200mV/A
  • Sensing Range: 10A
  • Output: Ratiometric voltage
  • Supply Voltage: 5V
  • Response Time: 13μs
  • Linearity: ±1%
