ACS710KLATR-25CB-T Real Image ACS710KLATR-25CB-T Real Image1 ACS710KLATR-25CB-T Real Image2
Same model may have multiple batches, images only for reference.
ACS710KLATR-25CB-T Real Image ACS710KLATR-25CB-T Real Image1 ACS710KLATR-25CB-T Real Image2
ACS710KLATR-25CB-T Real Image ACS710KLATR-25CB-T Real Image1 ACS710KLATR-25CB-T Real Image2
Same model may have multiple batches, images only for reference.

ACS710KLATR-25CB-T

Part No ACS710KLATR-25CB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Sense Transformers
Description 120 kHz Bandwidth, High Voltage Isolation Current Sensor with Integrated Overcurrent Detection | SENSOR CURRENT HALL 25A AC/DC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel
Part Status Last Time Buy
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 25A
Output Ratiometric, Voltage
Sensitivity 28mV/A
Frequency DC ~ 120kHz
Linearity ±0.25%
Accuracy ±2.9%
Supply Voltage (V) 3V ~ 5.5V
Response Time 4μs
Maximum Supply Current 14.5mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Bidirectional
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1135509-ACS710KLATR-25CB-T
Manufacturer Homepage www.avagotech.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ACS710KLATR-25CB-T CAD Model

Description

The ACS710KLATR-25CB-T is a bidirectional Hall effect current sensor designed for measuring AC/DC current up to 25A.

  • Sensitivity: 28mV/A
  • Accuracy: ±2.9%
  • Output: ratiometric and voltage output
  • Response Time: 4μs
  • Frequency Range: DC ~ 120kHz
  • Package: 16-SOIC package
  • Operating Temperature Range: -40°C ~ 125°C
  • Ideal for: use in sensors and transducers applications.
