AAT1150IKS-1.8-T1

Part No AAT1150IKS-1.8-T1
Manufacturer Advanced Analog Technology
Catalog Hard To Find
Description 1MHz 1A Step-Down DC/DC Converter
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Advanced Analog Technology
Win Source Part Number 1134909-AAT1150IKS-1.8-T1
Manufacturer Homepage www.analogictech.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian AAT1150IKS-1.8-T1 CAD Model

Description

The AAT1150IKS-1.8-T1 is a high-efficiency step-down (buck) DC-DC converter manufactured by Advanced Analog Technology (now Skyworks Solutions). It's designed to provide a regulated 1.8V output voltage from a higher input voltage. The 'AAT1150' denotes the product family, 'IKS' likely indicates the package type, '1.8' represents the fixed output voltage, and 'T1' signifies the tape and reel packaging for automated assembly.

Applications

  • Point-of-load regulation in portable devices
  • Powering microprocessors and microcontrollers
  • Voltage regulation in battery-powered applications
  • Mobile phones and smartphones
  • PDAs and handheld devices

Features

  • High Efficiency: Maximizes battery life in portable applications.
  • Fixed 1.8V Output Voltage: Provides a stable and accurate output voltage.
  • Step-Down (Buck) Converter: Efficiently converts a higher input voltage to a lower output voltage.
  • Current Limiting: Protects the converter and the load from overcurrent conditions.
  • Thermal Shutdown Protection: Prevents damage from overheating.
  • Small Package: Suitable for space-constrained applications.

Benefits

  • Extended Battery Life: High efficiency minimizes power consumption.
  • Stable Power Supply: Provides a consistent and reliable voltage source.
  • Overload Protection: Protects the converter and connected devices from damage.
  • Improved System Reliability: Thermal shutdown prevents overheating and potential failures.
  • Compact Design: Small package allows for integration into portable devices.

Technical Specifications

The following specifications are typical for the AAT1150 series. Refer to the Advanced Analog Technology (Skyworks Solutions) datasheet for the exact specifications of the AAT1150IKS-1.8-T1.

  • Input Voltage Range: Typically 2.7V to 5.5V
  • Output Voltage: 1.8V (Fixed)
  • Output Current: Up to 600mA (Typical)
  • Switching Frequency: Typically 1.5 MHz
  • Efficiency: Up to 95% (depending on input voltage and load)
  • Operating Temperature Range: -40°C to +85°C
  • Package: IKS (likely a small outline package such as SOT-23 or similar)

It is important to consult the manufacturer's datasheet for the most accurate and up-to-date specifications for this component. The datasheet will provide detailed information on parameters such as ripple voltage, load regulation, and transient response.
