ABM3B-8.000MHZ-B2-T Real Image ABM3B-8.000MHZ-B2-T real image21473 ABM3B-8.000MHZ-B2-T Real Image1 ABM3B-8.000MHZ-B2-T Real Image2
Same model may have multiple batches, images only for reference.
ABM3B-8.000MHZ-B2-T Real Image ABM3B-8.000MHZ-B2-T real image21473 ABM3B-8.000MHZ-B2-T Real Image1 ABM3B-8.000MHZ-B2-T Real Image2
ABM3B-8.000MHZ-B2-T Real Image ABM3B-8.000MHZ-B2-T real image21473 ABM3B-8.000MHZ-B2-T Real Image1 ABM3B-8.000MHZ-B2-T Real Image2
Same model may have multiple batches, images only for reference.

ABM3B-8.000MHZ-B2-T

Part No ABM3B-8.000MHZ-B2-T
Manufacturer Abracon LLC
Catalog Crystals
Description CRYSTAL 8.0000MHZ 18PF SMD
Datasheet
ABM3B-8.000MHZ-B2-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Crystals, Oscillators, Resonators
Manufacturer Abracon LLC
Series ABM3B
Packaging Reel package
Type MHz Crystal
Frequency 8MHz
Frequency Stability ±50ppm
Frequency Tolerance ±20ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 200 Ohm
Operating Mode Fundamental
Operating Temperature Range -20°C ~ 70°C
Mounting SMD
Package 4-SMD, No Lead
Dimension 0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Maximum) 0.043" (1.10mm)
Win Source Part Number 766874-ABM3B-8.000MHZ-B2-T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ABM3B-8.000MHZ-B2-T CAD Model

Description

The ABM3B series 8 MHz crystal by Abracon LLC is a versatile and reliable component for use in a variety of electronic applications.

  • Series: ABM3B
  • Frequency: 8 MHz
  • Operating Temperature Range: -20°C to 70°C
  • Package: 4-SMD, no lead
  • Pieces per Package: 3000
  • Categories: Crystals, Oscillators, and Resonators
  • Popularity: High
  • ECCN: EAR99
  • Halogen Free: Yes
