ABM10-22.1184MHZ-D30-T3 Abracon LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ABM10-22.1184MHZ-D30-T3

Part No ABM10-22.1184MHZ-D30-T3
Manufacturer Abracon LLC
Catalog Crystals
Description CRYSTAL 22.1184MHZ 10PF SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type MHz Crystal
Frequency 22.1184 MHz
Frequency Stability ±30ppm
Frequency Tolerance ±20ppm
Load Capacitance 10pF
ESR (Equivalent Series Resistance) 100 Ohms
Operating Mode Fundamental
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Case / Package 4-SMD, No Lead
Supplier Device Package 4-SMD (2.5x2)
Size / Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max) 0.028\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1528602-ABM10-22.1184MHZ-D30-T3
Ultra Librarian 3D Model Ultra Librarian ABM10-22.1184MHZ-D30-T3 CAD Model
