The LPF3010T-6R8M is a power inductor manufactured by ABCO ELECTRONICS CO. LTD. It is designed for use in DC-DC converters and power supply circuits. This inductor is characterized by its compact size, low DC resistance, and high current handling capability.

Applications:

• DC-DC converters (Buck, Boost)
• Power supply filtering
• Voltage regulators
• Point-of-Load (POL) converters
• Portable electronic devices

Features:

• Compact size: Designed for space-constrained applications.
• Low DC resistance: Minimizes power losses and improves efficiency.
• High current handling: Capable of handling large currents without saturation.
• Shielded construction: Reduces electromagnetic interference (EMI).
• Surface mount design: Simplifies assembly and integration.

Benefits:

• Increased efficiency: Low DCR results in lower power dissipation and higher efficiency.
• Reduced EMI: Shielding minimizes radiated noise, improving overall system performance.
• Space savings: Compact size allows for denser circuit designs.
• Easy integration: Surface mount package simplifies assembly.
• Reliable performance: Designed for stable operation under varying load conditions.

Technical Specifications:

The LPF3010T-6R8M has an inductance of 6.8uH (indicated by 6R8M, where 'R' denotes the decimal). The '3010' likely refers to dimensions, approximately 3.0mm x 3.0mm with a height of 1.0mm. Consult the ABCO ELECTRONICS datasheet for precise values on saturation current, DCR, and SRF for the LPF3010T series. Typical operating temperature range is -40°C to +125°C. Termination material is typically tin plating for ease of soldering. The core is likely a ferrite composition selected for performance at intended frequencies. The inductor is RoHS compliant.
