4311-111-00245 Real Image
Same model may have multiple batches, images only for reference.

4311-111-00245

Part No 4311-111-00245
Manufacturer Yageo
Catalog RF Antennas
Description ANTENNA 802.11B REG BLUTOOTH SMD
Datasheet
4311-111-00245 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Yageo
Packaging Reel - TR
Status Obsolete(EOL)
Frequency Group UHF (2 GHz to 3 GHz)
Frequency (Center/Band) 2.4GHz
Frequency Range 2.4GHz to 2.5GHz
Antenna Type Chip
Number of Bands 1
VSWR 2
Gain 1.2dBi
Maximum Power Dissipation 1W
Termination Solder
Mounting SMD (SMT)
Height (Max) 0.051" (1.30mm)
Applications Bluetooth, WLAN
Win Source Part Number 1027594-4311-111-00245
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 4311-111-00245 CAD Model

Description

The Yageo 4311-111-00245 is a chip antenna manufactured by Yageo.

  • Application: Bluetooth, WLAN
  • Mounting Type: SMD (SMT)
  • Packaging: Reel - TR
  • Frequency Range: 2.4GHz to 2.5GHz
  • Frequency Group: UHF (2 GHz to 3 GHz)
  • Frequency Band/Center: 2.4GHz
  • Antenna Type: Chip
  • Number of Bands: 1
  • VSWR: 2
  • Gain: 1.2dBi
  • Power Dissipation (Max): 1W
  • Height: 0.051" (1.30mm)
  • Status: Obsolete (EOL)
  • Supply and Demand Status: Balanced
