XCR3256XL-7TQ144C Xilinx Inc. XCR3256XL-7TQ144C Real Image XCR3256XL-7TQ144C label picture XCR3256XL-7TQ144C real image
Same model may have multiple batches, images only for reference.
XCR3256XL-7TQ144C Xilinx Inc. XCR3256XL-7TQ144C Real Image XCR3256XL-7TQ144C label picture XCR3256XL-7TQ144C real image
XCR3256XL-7TQ144C Xilinx Inc. XCR3256XL-7TQ144C Real Image XCR3256XL-7TQ144C label picture XCR3256XL-7TQ144C real image
Same model may have multiple batches, images only for reference.

XCR3256XL-7TQ144C

Part No XCR3256XL-7TQ144C
Manufacturer Xilinx Inc.
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 256MC 7NS 144TQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Xilinx Inc.
Packaging Tray
Status Active
Programmable Type In System Programmable (min 1K program/erase cycles)
Delay Time tpd(1) Max 7.0ns
Voltage Supply - Internal 3 V to 3.6 V
Number of Logic Elements/Blocks 16
Number of Macrocells 256
Number of Gates 6000
Number of I/O 120
Temperature Range - Operating 0°C to 70°C (TA)
Mounting Sub-Base Mount
Case / Package 144-TQFP (20x20)
Win Source Part Number 084830-XCR3256XL-7TQ144C
Family Name XCR3256XL
Introduction Date May 01, 1996
ECCN EAR99
Country of Origin Philippines, Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian XCR3256XL-7TQ144C CAD Model

Description

The XCR3256XL-7TQ144C by Xilinx Inc. is a high-performance in-system programmable CPLD.

  • Number of Gates: 6000
  • Number of Logic Elements/Blocks: 16
  • Number of Macrocells: 256
  • Delay Time tpd(1) max: 7.0ns
  • Programmable Type: Minimum of 1K cycles
  • Internal Voltage Supply: 3 V to 3.6 V
  • Mounting Type: 144-TQFP (20x20) sub-base tray
  • Supply and Demand Status: Balanced
  • Compliance: Halogen-free regulations
