74457215 Wurth Electronics Inc
Same model may have multiple batches, images only for reference.

74457215

Part No 74457215
Manufacturer Wurth Electronics Inc
Catalog Fixed Inductors
Description WE-PD4 SMT POWER INDUCTOR 150 UH
Datasheet
74457215 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Wurth Electronics Inc
Series WE-PD4
Package Tape & Reel
Product Status Active
Type Wirewound
Material - Core Metal Composite
Inductance 150 µH
Tolerance ±10%
Current Rating (Amps) 1.5 A
Current - Saturation (Isat) 2.6A
Shielding Shielded
DC Resistance (DCR) 268mOhm Max
Frequency - Self Resonant 4.1MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.866" L x 0.591" W (22.00mm x 15.00mm)
Height - Seated (Max) 0.307" (7.80mm)
Standard Package 250 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 547326-74457215
Ultra Librarian 3D Model Ultra Librarian 74457215 CAD Model

Description

The WE-PD4 series from Wurth Electronics Inc is a wirewound inductor designed for use in various electronic applications.

  • Size: 0.866" L x 0.591" W (22.00mm x 15.00mm)
  • Inductance: 150 µH
  • Tolerance: ±10%
  • Design: Shielded
  • Packaging: Tape & reel
  • Seated Height: 0.307" (7.80mm)
  • DC Resistance (DCR): 268mOhm max
  • Temperature Range: -40°C to 125°C
  • Current Rating: 1.5 A
  • Manufacturer: Wurth Electronics Inc
