74453122 Wurth Electronics Inc
Same model may have multiple batches, images only for reference.

74453122

Part No 74453122
Manufacturer Wurth Electronics Inc
Catalog Fixed Inductors
Description WE-PD3 SMT SHIELDED POWER INDUCT
Datasheet
74453122 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Wurth Electronics Inc
Series WE-PD3
Package Tape & Reel
Product Status Active
Type Wirewound
Material - Core Ferrite
Inductance 22 µH
Tolerance ±20%
Current Rating (Amps) 800 mA
Current - Saturation (Isat) 1.9A
Shielding Shielded
DC Resistance (DCR) 300mOhm Max
Frequency - Self Resonant 18MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.500" L x 0.398" W (12.70mm x 10.10mm)
Height - Seated (Max) 0.118" (3.00mm)
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 547309-74453122
Ultra Librarian 3D Model Ultra Librarian 74453122 CAD Model

Description

The WE-PD3 series from Wurth Electronics Inc. is a reliable choice for fixed inductors in electronic circuits. This particular component, with a part number of 547309-74453122, is a wirewound inductor with a compact size of 0.500" L x 0.398" W (12.70mm x 10.10mm).

  • Type: Wirewound Inductor
  • Size: 0.500" L x 0.398" W (12.70mm x 10.10mm)
  • Inductance: 22 µH
  • Tolerance: ±20%
  • DC Resistance (DCR): Within 300mOhm
  • Mounting Type: Surface Mount
  • Package: Tape & Reel
  • Temperature Range: -40°C to 125°C
  • Core Material: Ferrite
  • Current Rating: 800 mA
