744284100 Real Image
Same model may have multiple batches, images only for reference.

744284100

Part No 744284100
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 10UH 2.75A 2LN 10K OHM SMD
Datasheet
744284100 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number 3000001137-744284100
Manufacturer Würth Elektronik
Category Filters -Common Mode Chokes
Series WE-SCC
Package Tape & Reel (TR) Cut Tape (CT)
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Operating Temperature -40°C ~ 125°C
Size / Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height (Max) 0.413" (10.50mm)
Current Rating (Max) 2.75A
Ultra Librarian 3D Model Ultra Librarian 744284100 CAD Model

Description

The WE-SCC series from Würth Elektronik is a range of common mode chokes designed for surface mount applications.

  • Mounting Type: Surface Mount
  • Size / Dimension: 0.492" L x 0.492" W (12.50mm x 12.50mm)
  • Current Rating (Max): 2.75A
  • Operating Temperature: -40°C ~ 125°C
  • Packaging: Tape & Reel (TR) / Cut Tape (CT)
