Part No 1031640000
Manufacturer Weidmuller
Catalog Headers, Plugs and Sockets
Description TERM BLOCK HDR 30POS VERT 3.81MM
Datasheet
1031640000 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Weidmüller
Category Connectors, Interconnects > Terminal Blocks > Headers, Plugs and Sockets
Packaging Bulk
Part Status Active
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 30
Positions Per Level 15
Number of Levels 2
Pitch 0.150" (3.81mm)
Header Orientation Vertical
Mounting Type Through Hole
Ultra Librarian 3D Model Ultra Librarian 1031640000 CAD Model

Description

High-temperature-resistant two-tier SCD-THR pin header for reflow soldering.

• It allows you to use two interfaces on only one surface and with only one step in the work flow.

• Outlet direction: 90° (recumbent)

• Connections at the same level and with access that is flush over the front board.

• Space for labelling and coding

• Packed in cardboard box.

Weidmüller's 3.81-mm-pitch (0.15 inch) plug-in connectors are compatible with the layouts of standard connectors and offer space for labelling and coding.
