The Z0107MA0 is a sensitive gate Triac intended for applications requiring direct interfacing with low power drivers, such as microcontrollers, logic ICs and other sensitive gate circuits. This Triac is designed for use in general purpose switching applications where gate sensitivity is crucial.

Applications

• Light dimmers
• Small motor control
• Solid state relays
• Heater control
• General purpose switching circuits

Features

• High static dV/dt capability
• Low holding current
• On-state RMS current: 1 A
• Repetitive peak off-state voltage: 600 V
• Gate triggering current: 5 mA

Benefits

• Direct interfacing with microcontrollers and logic circuits due to its sensitive gate characteristic.
• Enhanced immunity to unwanted triggering due to its high static dV/dt capability.
• Suitable for driving inductive loads.
• Cost-effective solution for AC switching applications.

Additional Details

The Z0107MA0 is a through-hole component available in a TO-92 package. It is designed to operate within a temperature range suitable for typical industrial and consumer applications. The device is capable of handling a repetitive peak off-state voltage of 600V, making it suitable for use in 230V AC mains applications. The low holding current ensures reliable switching even with low load currents. It is RoHS compliant.
