BTA420Y-800BT,127 WeEn Semiconductors BTA420Y-800BT,127 real image
Same model may have multiple batches, images only for reference.
BTA420Y-800BT,127 WeEn Semiconductors BTA420Y-800BT,127 real image
BTA420Y-800BT,127 WeEn Semiconductors BTA420Y-800BT,127 real image
Same model may have multiple batches, images only for reference.

BTA420Y-800BT,127

Part No BTA420Y-800BT,127
Manufacturer WeEn Semiconductors
Catalog Triacs
Description TRIAC 800V 20A TO220AB / TRIAC 800V 20A(RMS) 220A 3-Pin(3+Tab) TO-220AB
Datasheet
BTA420Y-800BT,127 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer WeEn Semiconductors
Packaging Tube
Triac Type Standard
Voltage - Off State 800V
Current - On State (It (RMS)) (Maximum) 20A
Voltage - Gate Trigger (Vgt) (Maximum) 1V
Current - Non Rep. Surge 50, 60Hz (Itsm) 200A, 220A
Current - Gate Trigger (Igt) (Maximum) 50mA
Current - Hold (Ih) (Maximum) 60mA
Configuration Single
Operating Temperature Range 150°C (TJ)
Mounting Style Through Hole
Package TO-220-3
Manufacturer Package TO-220AB
Win Source Part Number 770555-BTA420Y-800BT,127
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1k pcs
Family Name BTA420Y-800BT
Introduction Date August 05, 2015
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BTA420Y-800BT,127 CAD Model

Description

The WeEn Semiconductors BTA420Y-800BT is a standard triac type device that is designed for use in various electronic applications.

  • Voltage Off State: 800V
  • Current Non-Rep. Surge: 200A, 220A
  • Current - on state (It (RMS)) (maximum): 20A
  • Voltage - gate trigger (Vgt) (maximum): 1V
  • Current - gate trigger (Igt) (maximum): 50mA
  • Current - hold (Ih) (maximum): 60mA
  • Package: TO-220-3
  • Supply and Demand Status: Limited
