FEATURES

• Temperature coefficient of resistance (TCR) absolute: ± 2 ppm/°C typical (- 55 °C to + 125 °C, + 25 °C ref.) TCR tracking: 0.5 ppm/°C
• Tolerance: absolute and matching to 0.005 % (50 ppm)
• Power rating: 0.2 W at 70 °C, for the entire resistive element R1 and R2, divided proportionally between the two values
• Load life ratio stability: < 0.005 % (50 ppm) 0.2 W at 70 °C for 2000 h
• Maximum working voltage: 200 V
• Resistance range: 100R to 20K per resistive element
• Vishay Foil resistors are not restricted to standard values/ratios; specific “as requested” values/ratios can be supplied at no extra cost or delivery (e.g. 1K2345 vs. 1K)
• Electrostatic discharge (ESD) up to 25 000 V
• Non-inductive, non-capacitive design
• Rise time: 1 ns effectively no ringing
