VS-50WQ10FNTRPBF Real Image VS-50WQ10FNTRPBF Real Image
Same model may have multiple batches, images only for reference.
VS-50WQ10FNTRPBF Real Image VS-50WQ10FNTRPBF Real Image
VS-50WQ10FNTRPBF Real Image VS-50WQ10FNTRPBF Real Image
Same model may have multiple batches, images only for reference.

VS-50WQ10FNTRPBF

Part No VS-50WQ10FNTRPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 100V 5.5A DPAK / Rectifier Diode Schottky 100V 5.5A 3-Pin(2+Tab) DPAK T/R
Datasheet
VS-50WQ10FNTRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 5.5A
Voltage - Forward (Vf) (Max) @ If 770mV @ 5A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 100V
Capacitance @ Vr, F 183pF @ 5V, 1MHz
Mounting SMD (SMT)
Case / Package D-PAK (TO-252AA)
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 057333-VS-50WQ10FNTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 2k pcs
Family Name VS-50WQ10FN
Introduction Date November 30, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian VS-50WQ10FNTRPBF CAD Model

Description

The Vishay VS-50WQ10FN Schottky diode is a fast recovery diode with a current rating of 5.5A and a maximum reverse voltage of 100V.

  • Current Rating: 5.5A
  • Maximum Reverse Voltage: 100V
  • Forward Voltage: 770mV @ 5A
  • Reverse Leakage Current: 1mA @ 100V
  • Capacitance: 183pF @ 5V and 1MHz
  • Suitable for: applications that require a fast switching speed
  • Package: D-PAK (TO-252AA)
  • Compliance: compliant with halogen-free requirements
  • Usage: common-used part with high popularity and a limited supply and demand status. in the open market.
