VS-20TQ040PBF

Name: VS-20TQ040PBF
Brand: Vishay
SKU: 761770
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	VS-20TQ040PBF
Manufacturer	Vishay
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 40V 20A TO220AC
Datasheet	VS-20TQ040PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Semiconductor Diodes Division
Packaging	Tube
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Maximum)	40V
Current - Average Rectified (Io)	20A
Voltage - Forward (Vf) (Maximum) @ If	570mV @ 20A
Speed	Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr	2.7mA @ 40V
Mounting Style	Through Hole
Package	TO-220-2
Manufacturer Package	TO-220AC
Operating Temperature - Junction	-55°C ~ 150°C
Win Source Part Number	761770-VS-20TQ040PBF
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	50
Family Name	VS-20TQ040
Introduction Date	June 19, 2007
ECCN	EAR99
Estimated EOL Date	Obsolete
Ultra Librarian 3D Model	Ultra Librarian VS-20TQ040PBF CAD Model

Alternative Products

Description

The Vishay Semiconductor Diodes Division VS-20TQ040PBF is a fast recovery Schottky diode that is designed for use in a variety of applications.

Current Rating: 20A
Voltage Rating: 40V
Forward Voltage Drop: 570mV @ 20A
Reverse Leakage Current: 2.7mA @ 40V
Operating Temperature Range: -55°C ~ 150°C
Package: TO-220-2
RoHS3 Compliant: Yes
