V15PN50-M3/86A Vishay V15PN50-M3/86A Real Image V15PN50-M3/86A label picture
Same model may have multiple batches, images only for reference.
V15PN50-M3/86A Vishay V15PN50-M3/86A Real Image V15PN50-M3/86A label picture
V15PN50-M3/86A Vishay V15PN50-M3/86A Real Image V15PN50-M3/86A label picture
Same model may have multiple batches, images only for reference.

V15PN50-M3/86A

Part No V15PN50-M3/86A
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Schottky 50V 15A 3-Pin(2+Tab) SMPC T/R / DIODE SCHOTTKY 50V 15A TO277A
Datasheet
V15PN50-M3/86A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 50V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Max) @ If 560mV @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 3mA @ 50V
Mounting SMD (SMT)
Case / Package TO-277A (SMPC)
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 098304-V15PN50-M3/86A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name V15PN50
Introduction Date May 13, 2013
ECCN EAR99
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian V15PN50-M3/86A CAD Model

Description

The Vishay V15PN50-M3/86A is a Schottky diode designed for use in a variety of applications, including power supplies, rectifiers, and reverse polarity protection.

  • Maximum Voltage Rating: 50V
  • Maximum Current Rating: 15A
  • Package: TO-277A (SMPC)
  • Status: Active
  • Popularity: High
  • Supply and Demand Status: Sufficient
  • Recovery Speed: 200mA (Io)
  • Operating Temperature: -40°C to 150°C
  • ECCN: EAR99
  • EOL Date: 2026
