TSOP6138TR Real Image
Same model may have multiple batches, images only for reference.

TSOP6138TR

Part No TSOP6138TR
Manufacturer Vishay
Catalog Optical Sensors - Photo Detectors - Remote Receiver
Description SMD PH.MODULE 38KHZ S.VIEW
Datasheet
TSOP6138TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Vishay Semiconductor Opto Division
Packaging Reel - TR
Sensing Distance 40m
B.P.F. Center Frequency 38.0kHz
Operating Supply Voltage 2.5 V ~ 5.5 V
Operating Supply Current 700μA
Orientation Side or Top View
Mounting SMD
Operating Temperature Range -25°C ~ 85°C (TA)
Manufacturer Vishay
Manufacturer Homepage www.vishay.com
Win Source Part Number 728058-TSOP6138TR
Popularity Medium
Supply and Demand Status Balance
Family Name TSOP6138__
Introduction Date April 06, 2009
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian TSOP6138TR CAD Model

Description

The Vishay TSOP6138TR is a sensor and transducer product that has an operating supply voltage of 2.5 V ~ 5.5 V.

  • Product Type: Sensor and Transducer
  • Operating Supply Voltage: 2.5 V ~ 5.5 V
  • Sensing Distance: 40m
  • B.P.F. Center Frequency: 38.0kHz
  • Operating Temperature Range: -25°C ~ 85°C (TA)
  • Mounting: SMD
