TCMT1100

Name: TCMT1100
Brand: Vishay
SKU: 360480
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TCMT1100
Manufacturer	Vishay
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin Mini-Flat T/R / OPTOISOLATOR 3.75KV TRANS 4-SOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	3750Vrms
Minimum DC Current Transfer Ratio	50% @ 5mA
Maximum DC Current Transfer Ratio	600% @ 5mA
Switching Turn-On and Turn-Off Time	9.5μs, 8.5μs
Rise and Fall Time	5.5μs, 7μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	70V
Channel Output Current	50mA
Forward Voltage	1.35V
Continuous forward current- Max	60mA
Vce Saturation (Max)	300mV
Temperature Range - Operating	-40°C to 100°C
Mounting	SMD (SMT)
Case / Package	4-SOP
Win Source Part Number	032039-TCMT1100
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Automation & Process Control, Communications & Networking, Industrial
Family Name	TCMT1100
Introduction Date	January 07, 2004
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2025
Ultra Librarian 3D Model	Ultra Librarian TCMT1100 CAD Model

Description

The TCMT1100 is a single-channel transistor output optocoupler from Vishay.

Isolation Voltage: 3750Vrms
Maximum Output Voltage: 70V
Switching Turn-On Time: 9.5μs
Switching Turn-Off Time: 8.5μs
Rise Time: 5.5μs
Fall Time: 7μs
Minimum DC Current Transfer Ratio: 50% @ 5mA
Maximum DC Current Transfer Ratio: 600% @ 5mA
Package: 4-SOP
Operating Temperature: -40°C to 100°C
