SFH6206-3T Real Image SFH6206-3T real image SFH6206-3T Real Image
Same model may have multiple batches, images only for reference.
SFH6206-3T Real Image SFH6206-3T real image SFH6206-3T Real Image
SFH6206-3T Real Image SFH6206-3T real image SFH6206-3T Real Image
Same model may have multiple batches, images only for reference.

SFH6206-3T

Part No SFH6206-3T
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 5.3KV TRANS 4-SMD
Datasheet
SFH6206-3T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 5300Vrms
Minimum DC Current Transfer Ratio 100% @ 10mA
Maximum DC Current Transfer Ratio 320% @ 10mA
Switching Turn-On and Turn-Off Time 3μs, 2.3μs
Rise and Fall Time 2μs, 2μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 60mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SMD
Win Source Part Number 1095376-SFH6206-3T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SFH6206
Introduction Date October 23, 2003
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian SFH6206-3T CAD Model

Description

The SFH6206-3T is an isolator manufactured by Vishay.

  • Forward Voltage: 1.25V
  • Isolation Voltage: 5300Vrms
  • Minimum DC Current Transfer Ratio: 100% @ 10mA
  • Maximum DC Current Transfer Ratio: 320% @ 10mA
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 2.3μs
  • Rise Time: 2μs
  • Fall Time: 2μs
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Package: 4-SMD
  • Applications: Suitable for use in a variety of applications including motor drives and power supplies
