SFH6156-4T

Name: SFH6156-4T
Brand: Vishay
SKU: 319131
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SFH6156-4T
Manufacturer	Vishay
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 5.3KV TRANS 4-SMD
Datasheet	SFH6156-4T Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	5300Vrms
Minimum DC Current Transfer Ratio	160% @ 10mA
Maximum DC Current Transfer Ratio	320% @ 10mA
Switching Turn-On and Turn-Off Time	3μs, 2.3μs
Rise and Fall Time	2μs, 2μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	70V
Channel Output Current	50mA
Forward Voltage	1.25V
Continuous forward current- Max	60mA
Vce Saturation (Max)	400mV
Temperature Range - Operating	-55°C to 100°C
Mounting	SMD (SMT)
Case / Package	4-SMD
Win Source Part Number	028259-SFH6156-4T
Family Name	SFH615A
Introduction Date	October 06, 2003
ECCN	EAR99
Country of Origin	Malaysia
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian SFH6156-4T CAD Model

Alternative Products

Description

The Vishay 326293 is an isolator with a transistor output type and a minimum DC current transfer ratio of 160 percent @ 10mA.

Output Type: Transistor
Minimum DC Current Transfer Ratio: 160% @ 10mA
Maximum DC Current Transfer Ratio: 320% @ 10mA
Switching Turn-On Time: 3µs
Switching Turn-Off Time: 2.3µs
Rise Time: 2µs
Maximum Output Voltage: 70V
Channel Output Current: 50mA
Continuous Forward Current: 60mA
Operating Temperature: -55°C to 100°C
Packaging: 4-SMD
