SFH6156-3X001T Real Image SFH6156-3X001T real image5344
Same model may have multiple batches, images only for reference.
SFH6156-3X001T Real Image SFH6156-3X001T real image5344
SFH6156-3X001T Real Image SFH6156-3X001T real image5344
Same model may have multiple batches, images only for reference.

SFH6156-3X001T

Part No SFH6156-3X001T
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 5.3KV TRANS 4SMD
Datasheet
SFH6156-3X001T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 5300Vrms
Minimum DC Current Transfer Ratio 100% @ 10mA
Maximum DC Current Transfer Ratio 200% @ 10mA
Switching Turn-On and Turn-Off Time 3μs, 2.3μs
Rise and Fall Time 2μs, 2μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 60mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SMD
Win Source Part Number 113844-SFH6156-3X001T
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SFH6156-3X001T CAD Model

Description

The SFH6156-3X001T is a high-speed, optically coupled transistor from Vishay.

  • Applications: High-speed switching applications, such as motor control, power supply control, and digital logic interfacing
  • Maximum Isolation Voltage: 5300 Vrms
  • Minimum DC Current Transfer Ratio: 100% @ 10 mA
  • Maximum Output Voltage: 70 V
  • Switching Speed & Saturation Voltage: Ideal for high-speed switching applications due to its fast switching speed and low saturation voltage
  • Availability: Readily available in the market
  • Supply and Demand: Balanced
