S1J-E3/61T Real Image S1J-E3/61T real image S1J-E3/61T label picture
Same model may have multiple batches, images only for reference.
S1J-E3/61T Real Image S1J-E3/61T real image S1J-E3/61T label picture
S1J-E3/61T Real Image S1J-E3/61T real image S1J-E3/61T label picture
Same model may have multiple batches, images only for reference.

S1J-E3/61T

Part No S1J-E3/61T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Switching 600V 1A 1800ns Automotive 2-Pin SMA T/R / DIODE GEN PURP 600V 1A DO214AC
Datasheet
S1J-E3/61T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 1A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) 1.8μs
Current - Reverse Leakage @ Vr 1μA @ 600V
Capacitance @ Vr, F 12pF @ 4V, 1MHz
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 027751-S1J-E3/61T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name S1G
Introduction Date June 23, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian S1J-E3/61T CAD Model

Description

The Vishay S1J-E3/61T is a SMD (SMT) mounted electronic component that belongs to the S1G family.

  • Manufacturer: Vishay
  • Part Number: S1J-E3/61T
  • Mounting: SMD (SMT)
  • Family: S1G
  • Type: Standard Diode
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 1.1V @ 1A
  • Reverse Recovery Time (trr): 1.8μs
  • Current - Reverse Leakage @ Vr: 1μA @ 600V
  • Capacitance @ Vr, F: 12pF @ 4V, 1MHz
  • Temperature Range - Operating: -55°C to 150°C
