PTCCL09H471DBE Vishay – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PTCCL09H471DBE

Part No PTCCL09H471DBE
Manufacturer Vishay
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 30V 470MA RADIAL
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Ceramic
Voltage - Max 30V
Current - Hold (Ih) (Max) 470 mA
Current - Trip (It) 705 mA
Current - Max 5 A
Resistance - 25°C (Typ) 2.5 Ohms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Case / Package Radial, Disc
Size / Dimension 0.335" Dia x 0.157" T (8.50mm x 4.00mm)
Height - Seated (Max) 0.532" (13.50mm)
Lead Spacing 0.197\
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1607874-PTCCL09H471DBE
Ultra Librarian 3D Model Ultra Librarian PTCCL09H471DBE CAD Model

Description

N
