P6SMB47CAHE3/52 Real Image P6SMB47CAHE3/52 real image17064
Same model may have multiple batches, images only for reference.
P6SMB47CAHE3/52 Real Image P6SMB47CAHE3/52 real image17064
P6SMB47CAHE3/52 Real Image P6SMB47CAHE3/52 real image17064
Same model may have multiple batches, images only for reference.

P6SMB47CAHE3/52

Part No P6SMB47CAHE3/52
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS DIODE 40.2VWM 64.8VC DO214AA
Datasheet
P6SMB47CAHE3/52 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Features 64.8V Clamp 9.3A Ipp Tvs Diode Surface Mount DO-214AA (SMB)
Manufacturer Vishay
Series Automotive, AEC-Q101, P6SMB, TransZorb®
Package Reel - TR
Operating Temperature Range -65°C ~ 150°C (TJ)
Mounting Surface Mount
Package DO-214AA, SMB
Case / Package DO-214AA (SMB)
Family Name P6SMB47
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Quantity per package 750
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 888445-P6SMB47CAHE3/52
Ultra Librarian 3D Model Ultra Librarian P6SMB47CAHE3/52 CAD Model

Description

The P6SMB47CAHE3/52 is a surface mount TVS diode manufactured by Vishay.

  • Clamp Voltage: 64.8V
  • Peak Pulse Current: 9.3A
  • Package: DO-214AA (SMB)
  • Supply and Demand Status: limited
  • Quantity per Package: 750
