MUR3020WTPBF Real Image MUR3020WTPBF real image MUR3020WTPBF label picture
Same model may have multiple batches, images only for reference.
MUR3020WTPBF Real Image MUR3020WTPBF real image MUR3020WTPBF label picture
MUR3020WTPBF Real Image MUR3020WTPBF real image MUR3020WTPBF label picture
Same model may have multiple batches, images only for reference.

MUR3020WTPBF

Part No MUR3020WTPBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 200V 15A TO247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) (per Diode) 15A
Voltage - Forward (Vf) (Max) @ If 1.05V @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 35ns
Current - Reverse Leakage @ Vr 10μA @ 200V
Operating Temperature - Junction -65°C to 175°C
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 059669-MUR3020WTPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MUR3020WTPBF CAD Model

Description

The Vishay MUR3020WTPBF is a standard diode with a maximum reverse voltage of 200V and a forward voltage of 1.05V @ 15A.

  • Maximum Reverse Voltage: 200V
  • Forward Voltage: 1.05V @ 15A
  • Frequency: 200mA
  • Reverse Recovery Time: 35ns
  • Diode Configuration: 1 pair common cathode
  • Average Rectified Current: 15A
  • Mounting: Through hole
  • Package: TO-247AC
  • Operating Temperature Range: between -65°C to 175°C
  • Supply and Demand Status: Limited

The operating temperature range of this diode is between -65°C to 175°C. However, the supply and demand status is limited.
