Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Vishay
Category Resistor Networks, Arrays
Series MPMT
Termination Style SMD/SMT
Resistor Values 10 kOhms, 10 kOhms
Tolerance 0.1 %
Circuit Type Divider
Number of Resistors 2 Resistor
Number of Pins 3 Pin
Minimum Operating Temperature - 55 C
Maximum Operating Temperature + 155 C
Package / Case TO-236 AB
Ultra Librarian 3D Model Ultra Librarian MPMT2002AT0 CAD Model

Description

Features

  • Excellent long term ratio stability<br />(ΔR ± 0.015 %, 2000 h, +70 °C)
  • Ratio tolerances to ± 0.01 %
  • Low TCR tracking ± 2 ppm
  • Zero ohm jumper option available
  • Standard JEDEC® TO-236 package variation AB
