LH1546ADFTR Real Image LH1546ADFTR real image10351 LH1546ADFTR Real Image
Same model may have multiple batches, images only for reference.
LH1546ADFTR Real Image LH1546ADFTR real image10351 LH1546ADFTR Real Image
LH1546ADFTR Real Image LH1546ADFTR real image10351 LH1546ADFTR Real Image
Same model may have multiple batches, images only for reference.

LH1546ADFTR

Part No LH1546ADFTR
Manufacturer Vishay
Catalog Solid State Relays
Description SMD-4 SSR GULLWING 1 FORM A
Datasheet
LH1546ADFTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Vishay
Packaging Reel - TR
Status Active
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Max On Resistance 28 Ohm
Load Current 120mA
Voltage - Input 1.2VDC
Voltage - Load 0 to 350 V
Mounting SMD (SMT)
Termination Style Gull Wing
Case / Package 4-SMD
Relay Type Relay
Win Source Part Number 1052521-LH1546ADFTR
Family Name LH1546ADF
Introduction Date August 28, 2001
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian LH1546ADFTR CAD Model

Description

The LH1546ADFTR is an electronic component manufactured by Vishay.

  • Popularity: High
  • Supply and Demand Status: Limited
  • Case/Package: 4-SMD
  • Max On Resistance: 28 Ohm
  • Circuit Relay Type: SPST-NO (1 Form A)
  • Load Current: 120mA
  • Voltage Load: 0 to 350 V
