IRF9540

Part No IRF9540
Manufacturer Vishay
Catalog FETs - Single
Description P-CHANNEL POWER MOSFETS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Vishay
Drain Current (Max) 19 A
Frequency (Max) Not Required MHz
Gate-Source Voltage (Max) ±20(V)
Output Power (Max) Not Required W
Power Dissipation 150(W)
Mounting Through Hole
Noise Figure Not Required dB
Drain-Source On-Res 0.2(ohm)
Operating Temp Range -55C to 175C
Package Type TO-220AB
Pin Count 3 +Tab
Polarity P
Type Power MOSFET
Number of Elements 1
Operating Temperature Classification Military
Channel Mode Enhancement
Drain Efficiency Not Required %
Drain-Source On-Volt 100(V)
Power Gain Not Required dB
Rad Hardened No
Continuous Drain Current 19(A)
DELETED Not Compliant
Win Source Part Number 040706-IRF9540
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management, Industrial, Portable Devices, Consumer Electronics
Ultra Librarian 3D Model Ultra Librarian IRF9540 CAD Model

Description

The Vishay IRF9540 is a P-channel power MOSFET with a TO-220AB package type.

  • Continuous Drain Current: 19A
  • Gate-Source Voltage (Max): ±20V
  • Drain-Source on-volt: 100V
  • Drain-Source on-res: 0.2 (ohm)
  • Voltage Peak Reverse (Max): 600V
  • Current Reverse Leakage @ Vr: 5μA @ 600V
  • Suitable for: use in power management, industrial, portable devices, and consumer electronics applications
  • Popularity: medium
  • Supply and Demand Status: limited
