Same model may have multiple batches, images only for reference.

IHLP2020CZER3R3M01

Name: IHLP2020CZER3R3M01
Brand: Vishay
SKU: 156112
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IHLP2020CZER3R3M01
Manufacturer	Vishay
Catalog	Fixed Inductors
Description	Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Powdered Iron 5A 0.0547Ohm DCR 2020 T/R / FIXED IND 3.3UH 5A 54.7 MOHM SMD
Datasheet	IHLP2020CZER3R3M01 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Inductors, Coils, Chokes
Manufacturer	Vishay
Packaging	Reel - TR
Status	Active
Type	Molded
Inductance	3.3μH
Tolerance	±20%
Current Rating	5A
Current - Saturation	8.5A
DC Resistance (DCR)	54.7 mOhm Max
Temperature Range - Operating	-55°C to 125°C
Frequency - Test	100kHz
Mounting	SMD (SMT)
Height - Seated (Max)	0.118" (3.00mm)
Win Source Part Number	017162-IHLP2020CZER3R3M01
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	2k pcs
Family Name	IHLP-2020CZ-01
Introduction Date	June 14, 2009
ECCN	EAR99
Country of Origin	China, Israel, United States of America
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IHLP2020CZER3R3M01 CAD Model

Alternative Products

Description

The Vishay inductor is a molded electronic component that is widely used in various applications.

Package: Reel-tr
Height: 0.118 inches
Current Rating: 5A
Inductance: 3.3μH
Mounting Style: SMD
Tolerance: ±20%
DC Resistance: 54.7 mOhm max
Current Saturation: 8.5A
Frequency Test: 100kHz
Temperature Range: -55°C to 125°C
Popularity: High
EOL date: 2027
Halogen-Free Regulations: Compliant
Country of Origin: China, Israel, and the United States of America
