IHLP2020CZER2R2M01 Real Image IHLP2020CZER2R2M01 label picture
Same model may have multiple batches, images only for reference.
IHLP2020CZER2R2M01 Real Image IHLP2020CZER2R2M01 label picture
IHLP2020CZER2R2M01 Real Image IHLP2020CZER2R2M01 label picture
Same model may have multiple batches, images only for reference.

IHLP2020CZER2R2M01

Part No IHLP2020CZER2R2M01
Manufacturer Vishay
Catalog Fixed Inductors
Description FIXED IND 2.2UH 5.8A 29.2 MOHM
Datasheet
IHLP2020CZER2R2M01 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Molded
Inductance 2.2μH
Tolerance ±20%
Current Rating 5.8A
Current - Saturation 10A
DC Resistance (DCR) 29.2 mOhm Max
Temperature Range - Operating -55°C to 125°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.118" (3.00mm)
Win Source Part Number 124274-IHLP2020CZER2R2M01
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian IHLP2020CZER2R2M01 CAD Model

Description

The Vishay IHLP2020CZER2R2M01 is a molded inductor that can handle a current rating of 5.8A and has an inductance of 2.2μH.

  • Current Rating: 5.8A
  • Inductance: 2.2μH
  • Height: 0.118 inches (3.00mm) when seated
  • Tolerance: ±20%
  • Current-Saturation: 10A
  • Frequency-Test: 100kHz
  • DC Resistance (DCR): 29.2 mOhm Max
  • Temperature Range: -55°C to 125°C
  • Category: Inductors, coils, and chokes
  • Packaging: Reel - TR packaging
  • Popularity: Medium
  • Package Quantity: 2k pcs
