DG9424DQ-T1-E3 Real Image DG9424DQ-T1-E3 Real Image1 DG9424DQ-T1-E3 Real Image2
Same model may have multiple batches, images only for reference.
DG9424DQ-T1-E3 Real Image DG9424DQ-T1-E3 Real Image1 DG9424DQ-T1-E3 Real Image2
DG9424DQ-T1-E3 Real Image DG9424DQ-T1-E3 Real Image1 DG9424DQ-T1-E3 Real Image2
Same model may have multiple batches, images only for reference.

DG9424DQ-T1-E3

Part No DG9424DQ-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH QUAD SPST 16TSSOP
Datasheet
DG9424DQ-T1-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Vishay
Packaging Reel - TR
Part Status Obsolete(EOL)
Switch Circuit SPST - NO
Number of Circuits 4
On-State Resistance (Maximum) 3 Ohm
Operating Supply Voltage 3 V ~ 16 V
Dual Voltage Supply ±3 V ~ 8 V
Switch Time (Ton, Toff) (Maximum) 51ns, 35ns
Charge Injection 38pC
Channel Capacitance (CS(off), CD(off)) 49pF, 37pF
Current - Leakage (IS(off)) (Maximum) 1nA
Crosstalk -77dB @ 1MHz
Operating Temperature Range -40°C ~ 85°C (TA)
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Manufacturer Homepage www.vishay.com
Win Source Part Number 730572-DG9424DQ-T1-E3
Popularity Medium
Supply and Demand Status Limited
Family Name DG9424
Introduction Date August 23, 2002
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date End of life (Obsolete)
Ultra Librarian 3D Model Ultra Librarian DG9424DQ-T1-E3 CAD Model

Description

The DG9424DQ-T1-E3 is an obsolete (EOL) integrated circuit from Vishay.

  • Applications: Switch Circuits
  • Switch Circuit: 4 channel SPST-NO
  • Package: 16-TSSOP (0.173", 4.40mm Width)
  • Temperature Range: -40°C to 85°C
  • Dual Voltage Supply: ±3 V ~ 8 V
  • On-State Resistance (Maximum): 3 Ohm
  • Switch Time (Ton, Toff) (Maximum): 51ns, 35ns
  • Current Leakage (IS(off)) (Maximum): 1nA
  • REACH: Unaffected
  • ECCN: EAR99
