Same model may have multiple batches, images only for reference.
CRCW12062R70JNEAIF Real Image
Same model may have multiple batches, images only for reference.

CRCW12062R70JNEAIF

Part No CRCW12062R70JNEAIF
Manufacturer Vishay
Catalog Chip Resistor - Surface Mount
Description RES SMD 2.7 OHM 5% 1/4W 1206 / 2.7 Ohms ±5% 0.25W, 1/4W Chip Resistor 1206 (3216 Metric) Automotive AEC-Q200, Pulse Withstanding Thick Film
Datasheet
CRCW12062R70JNEAIF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors>Chip Resistor - Surface Mount
Mfr Vishay Dale
Series CRCW-IF
Package Tape & Reel
Resistance 2.7 Ohms
Tolerance ±5%
Power (Watts) 0.25W, 1/4W
Composition Thick Film
Features Automotive AEC-Q200, Pulse Withstanding
Temperature Coefficient ±200ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case 1206 (3216 Metric)
Supplier Device Package 1206
Ratings AEC-Q200
Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max) 0.024" (0.60mm)
Number of Terminations 2
Base Product Number CRCW1206
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8533.21.0030
Other Names 541-CRCW12062R70JNEAIFTR,541-CRCW12062R70JNEAIFDKR,541-CRCW12062R70JNEAIFCT,CRCW12062R70JNEAIF-ND
Standard Package 5,000
Win Source Part Number 1114998-CRCW12062R70JNEAIF
Ultra Librarian 3D Model Ultra Librarian CRCW12062R70JNEAIF CAD Model

Description

The Vishay CRCW12062R70JNEAIF is a chip resistor that has a tolerance of ±5 percent and a temperature coefficient of ±200ppm/°C.

  • Power Rating: 0.25W
  • Resistance: 2.7 Ohms
  • Series: CRCW-IF
  • Standard Package: 5,000
  • Automotive AEC-Q200 compliant: Yes
