CRCW120622R0JNEAIF Real Image
Same model may have multiple batches, images only for reference.

CRCW120622R0JNEAIF

Part No CRCW120622R0JNEAIF
Manufacturer Vishay
Catalog Chip Resistor - Surface Mount
Description RES SMD 22 OHM 5% 1/4W 1206 / 22 Ohms ±5% 0.25W, 1/4W Chip Resistor 1206 (3216 Metric) Automotive AEC-Q200, Pulse Withstanding Thick Film
Datasheet
CRCW120622R0JNEAIF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors>Chip Resistor - Surface Mount
Mfr Vishay Dale
Series CRCW-IF
Package Tape & Reel
Resistance 22 Ohms
Tolerance ±5%
Power (Watts) 0.25W, 1/4W
Composition Thick Film
Features Automotive AEC-Q200, Pulse Withstanding
Temperature Coefficient ±200ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case 1206 (3216 Metric)
Supplier Device Package 1206
Ratings AEC-Q200
Dimension 0.126" L x 0.063" W (3.20mm x 1.60mm)
Height - Seated (Max) 0.024" (0.60mm)
Number of Terminations 2
Base Product Number CRCW1206
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8533.21.0030
Other Names 541-22ARCT,541-22ARTR,541-22ARDKR
Standard Package 5,000
Win Source Part Number 1024464-CRCW120622R0JNEAIF
Ultra Librarian 3D Model Ultra Librarian CRCW120622R0JNEAIF CAD Model

Description

The Vishay CRCW120622R0JNEAIF is a thick film chip resistor with a resistance of 22 Ohms and a tolerance of ±5%.

  • Manufacturer: Vishay
  • Product Name: CRCW120622R0JNEAIF
  • Type: Thick Film Chip Resistor
  • Resistance: 22 Ohms
  • Tolerance: ±5%
  • Power Rating: 0.25W
  • Application: Automotive
  • Feature: Pulse Withstanding
  • Package: 1206 (3216 metric)
  • Height: 0.024" (0.60mm)
  • Packaging: Tape and Reel
  • AEC-Q200: Yes
  • Failure Rate: 70
  • Applications: Power Supplies, Automotive Electronics, and Consumer Electronics
