63CPQ100PBF Vishay 63CPQ100PBF Real Image 63CPQ100PBF label picture 2 63CPQ100PBF Real Image
Same model may have multiple batches, images only for reference.
63CPQ100PBF Vishay 63CPQ100PBF Real Image 63CPQ100PBF label picture 2 63CPQ100PBF Real Image
63CPQ100PBF Vishay 63CPQ100PBF Real Image 63CPQ100PBF label picture 2 63CPQ100PBF Real Image
Same model may have multiple batches, images only for reference.

63CPQ100PBF

Part No 63CPQ100PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 100V TO247
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 770mV @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 300μA @ 100V
Operating Temperature - Junction -55°C to 175°C
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 088899-63CPQ100PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 63CPQ100PBF CAD Model

Description

63CPQ100PBF

The 63CPQ100PBF is an energy-efficient diode ideal for high-frequency applications where performance and longevity are paramount. Its low leakage current and fast recovery time optimize system efficiency.

  • Applications:
    • Telecommunication Devices
    • Data Centers
    • Uninterruptible Power Supplies (UPS)
  • Features & Benefits:
    • High Efficiency
    • Fast Switching
    • Environmentally Friendly RoHS Compliant
  • Additional Details: Its construction promotes low thermal resistance, making it perfect for applications that demand high performance and minimal electronic noise.
