19TQ015STRL Real Image 19TQ015STRL real image16928
Same model may have multiple batches, images only for reference.
19TQ015STRL Real Image 19TQ015STRL real image16928
19TQ015STRL Real Image 19TQ015STRL real image16928
Same model may have multiple batches, images only for reference.

19TQ015STRL

Part No 19TQ015STRL
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description SCHOTTKY RECTIFIER | DIODE SCHOTTKY 15V 19A D2PAK
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Tape and Reel
Status Obsolete
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 15V
Current - Average Rectified (Io) 19A
Voltage - Forward (Vf) (Maximum) at If 360mV at 19A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1.5mA at 15V
Mounting Style SMD
Manufacturer Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Supplier Device Package D2PAK
Operating Temperature - Junction -55°C ~ 125°C
Family Part Number 19TQ015
Manufacturer Pack Quantity 800
MSL Level 1 (Unlimited)
Win Source Part Number 1121572-19TQ015STRL
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 19TQ015STRL CAD Model

Description

The 19TQ015STRL is a Schottky diode manufactured by Vishay Semiconductor Diodes Division.

  • Supply and Demand Status: Limited
  • Applications: High-frequency rectification and switching applications
  • Maximum Forward Voltage: 360mV @ 19A
  • Maximum Reverse Voltage: 15V
  • Package: D2PAK
  • RoHS Compliant: Yes
