TY-302P

Part No TY-302P
Manufacturer Triad Magnetics
Catalog Audio Transformers
Description AUDIO XFMR 600 / 600/600 TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Turns Ratio - Primary 1:1.47
Impedance - Primary (Ohms) 600
Impedance - Secondary (Ohms) 600/600
DC Resistance (DCR) - Primary 34Ohm
DC Resistance (DCR) - Secondary 24Ohm, 24Ohm
Transformer Type Data/Voice Coupling
Frequency Range 300Hz ~ 3.5kHz
Voltage - Isolation 1500VAC
Insertion Loss 0.65dB Typ
Return Loss 32dB Typ
Power Level -45dB ~ 7dB
Temperature Range - Operating -20°C ~ 85°C
Mounting Type Through Hole
Size / Dimension 1.040" L x 0.960" W (26.42mm x 24.38mm)
Height - Seated (Max) 0.870" (22.10mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1511160-TY-302P
Ultra Librarian 3D Model Ultra Librarian TY-302P CAD Model
