Same model may have multiple batches, images only for reference.

TEN 25-2422

Name: TEN 25-2422
Brand: Traco Power
SKU: 1335657
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	TEN 25-2422
Manufacturer	Traco Power
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-12V 30W / Isolated Module DC DC Converter 2 Output 12V -12V 1.25A, 1.25A 18V - 36V Input
Datasheet	TEN 25-2422 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Manufacturer	Traco Power
Packaging	Tube
Product Status	Not For New Designs
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	12V
Voltage - Output 2	-12V
Current - Output (Max)	1.25A, 1.25A
Power (Watts)	30 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OVP, SCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	89%
Mounting	Through Hole
Case / Package	7-DIP Module
Size / Dimension	2.00" L x 1.60" W x 0.37" H (50.8mm x 40.6mm x 9.5mm)
Base Product Number	TEN 25
RoHS Status	ROHS3 Compliant
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Other Part Number	1951-2988,TEN25-2422-ND,TEN25-2422
Standard Package	5
Win Source Part Number	1335657-TEN 25-2422
Ultra Librarian 3D Model	Ultra Librarian TEN 25-2422 CAD Model

Alternative Products

Description

The Traco Power TEN 25-2422 is an isolated module DC-DC converter that offers remote On/Off, OCP, OVP, and SCP features.

Power Rating: 30W
Voltage Isolation: 1.5kV
Number of Outputs: Two
Maximum Current Output: 1.25A each
Input Voltage: 18V to 36V
Output Voltage: 12V and -12V
Efficiency: 89%
Case/Package: 7-DIP module
Application: ITE (Commercial)
Operating Temperature: -40°C to 85°C (With Derating)
