TLP627(F) Real Image1 TLP627(F) Real Image2 TLP627(F) label picture TLP627(F) real image TLP627(F) Real Image
Same model may have multiple batches, images only for reference.
TLP627(F) Real Image1 TLP627(F) Real Image2 TLP627(F) label picture TLP627(F) real image TLP627(F) Real Image
TLP627(F) Real Image1 TLP627(F) Real Image2 TLP627(F) label picture TLP627(F) real image TLP627(F) Real Image
Same model may have multiple batches, images only for reference.

TLP627(F)

Part No TLP627(F)
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 1-CH Darlington DC-OUT 4-Pin PDIP / OPTOISOLTR 5KV DARLINGTON 4-DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Tube/Rail
Status Not For New Designs
Number of Channels 1
Isolation Voltage 5000Vrms
Minimum DC Current Transfer Ratio 1000% @ 1mA
Switching Turn-On and Turn-Off Time 50μs, 15μs
Rise and Fall Time 40μs, 15μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 300V
Channel Output Current 150mA
Forward Voltage 1.15V
Continuous forward current- Max 60mA
Vce Saturation (Max) 1.2V
Temperature Range - Operating -55°C to 100°C
Mounting Through Hole
Case / Package 4-DIP
Win Source Part Number 370642-TLP627(F)
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TLP627
Introduction Date February 26, 1998
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian TLP627(F) CAD Model

Description

It has sufficient supply and demand status.

  • Type: This product is a Darlington output type isolator.
  • Forward Voltage: a 1.15V forward voltage.
  • Isolation Voltage: 5000Vrms isolation voltage.
  • Min DC Current Transfer Ratio: It has a minimum DC current transfer ratio of 1000% @ 1mA.
  • Max Output Voltage: a maximum output voltage of 300V.
  • Switching Turn-On and Turn-Off Time: The switching turn-on and turn-off time is 50μs and 15μs respectively.
  • Rise and Fall Time: the rise and fall time is 40μs and 15μs respectively.
  • Manufacturer Homepage: For more information about this product, please visit the manufacturer's homepage at www.semicon.toshiba.co.jp/eng.
