TLP557(F)

Name: TLP557(F)
Brand: Toshiba Semiconductor and Storage
SKU: 936814
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP557(F)
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Special Purpose
Description	OPTOISO 2.5KV TRANS INVERTR 8DIP / Optoisolator Power Transistor Driver 2500Vrms 1 Channel 8-DIP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators - Special Purpose Isolators
Mfr	Toshiba Semiconductor and Storage
Package	Tube
Product Status	Obsolete
Type	Power Transistor Driver
Number of Channels	1
Voltage - Isolation	2500Vrms
Common Mode Transient Immunity (Min)	2kV/µs
Input Type	DC
Current - Output / Channel	320mA
Propagation Delay tpLH / tpHL (Max)	5µs, 5µs
Rise / Fall Time (Typ)	50ns, 50ns
Voltage - Forward (Vf) (Typ)	1.55 V
Current - DC Forward (If) (Max)	25 mA
Voltage - Supply	5V ~ 13V
Temperature Range - Operating	-30°C ~ 70°C
Mounting Type	Through Hole
Package / Case	8-DIP (0.300", 7.62mm)
Supplier Device Package	8-DIP
Approval Agency	UR
Base Product Number	TLP557
Standard Package	50 pcs
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8541.49.8000
Win Source Part Number	936814-TLP557(F)
Ultra Librarian 3D Model	Ultra Librarian TLP557(F) CAD Model

Alternative Products

Description

The 936814-TLP557(F) is a power transistor driver from Toshiba Semiconductor and Storage.

Application: Special Purpose Isolators
Voltage Isolation: 2500Vrms
Forward Current (If): 25mA
Forward Voltage (Vf): 1.55V
Rise and Fall Time: 50ns
Current Output: 320mA
Voltage Supply Range: 5V to 13V
Mounting: Through-Hole
Package: 8-DIP
Operating Temperature Range: -30°C to 70°C
Product Status: Obsolete
