TLP293-4(4LGBTRE Real Image TLP293-4(4LGBTRE Real Image1 TLP293-4(4LGBTRE Real Image2 TLP293-4(4LGBTRE Real Image3
Same model may have multiple batches, images only for reference.
TLP293-4(4LGBTRE Real Image TLP293-4(4LGBTRE Real Image1 TLP293-4(4LGBTRE Real Image2 TLP293-4(4LGBTRE Real Image3
TLP293-4(4LGBTRE Real Image TLP293-4(4LGBTRE Real Image1 TLP293-4(4LGBTRE Real Image2 TLP293-4(4LGBTRE Real Image3
Same model may have multiple batches, images only for reference.

TLP293-4(4LGBTRE

Part No TLP293-4(4LGBTRE
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS SO16
Datasheet
TLP293-4(4LGBTRE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 500μA
Maximum DC Current Transfer Ratio 600% @ 500μA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 1108905-TLP293-4(4LGBTRE
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian TLP293-4(4LGBTRE CAD Model

Description

The supply and demand status of this product is sufficient.

  • Minimum DC Current Transfer Ratio: 100% @ 500μA
  • Maximum DC Current Transfer Ratio: 600% @ 500μA
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 3μs
  • Rise Time: 2μs
  • Fall Time: 3μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
