TLP290-4 Toshiba Semiconductor and Storage TLP290-4 real image7467 TLP290-4 real image7468 TLP290-4 Real Image1 TLP290-4 Real Image2 TLP290-4 Real Image3 TLP290-4 Real Image4 TLP290-4 Real Image5
Same model may have multiple batches, images only for reference.
TLP290-4 Toshiba Semiconductor and Storage TLP290-4 real image7467 TLP290-4 real image7468 TLP290-4 Real Image1 TLP290-4 Real Image2 TLP290-4 Real Image3 TLP290-4 Real Image4 TLP290-4 Real Image5
TLP290-4 Toshiba Semiconductor and Storage TLP290-4 real image7467 TLP290-4 real image7468 TLP290-4 Real Image1 TLP290-4 Real Image2 TLP290-4 Real Image3 TLP290-4 Real Image4 TLP290-4 Real Image5
Same model may have multiple batches, images only for reference.

TLP290-4

Part No TLP290-4
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 4CH TRANS 16-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 100560-TLP290-4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLP290-4 CAD Model

Description

The TLP290-4 is an optoisolator manufactured by Toshiba Semiconductor and Storage.

  • Popularity: medium-popularity
  • Category: isolators
  • Channels: four channels
  • Maximum Output Voltage: 80V
