TLP185(GR-TPL,SE Toshiba Semiconductor and Storage TLP185(GR-TPL,SE Real Image
Same model may have multiple batches, images only for reference.
TLP185(GR-TPL,SE Toshiba Semiconductor and Storage TLP185(GR-TPL,SE Real Image
TLP185(GR-TPL,SE Toshiba Semiconductor and Storage TLP185(GR-TPL,SE Real Image
Same model may have multiple batches, images only for reference.

TLP185(GR-TPL,SE

Part No TLP185(GR-TPL,SE
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Transistor Output Optocouplers X36 PBF Trans Opto couplr 110C3750Vrms
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 300% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 6-SO, 4 Lead
Win Source Part Number 1108856-TLP185(GR-TPL,SE
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TLP185
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian TLP185(GR-TPL,SE CAD Model

Description

The Toshiba Semiconductor and Storage TLP185 is an isolator with a transistor output type. It has a minimum DC current transfer ratio of 100% @ 5mA and a maximum DC current transfer ratio of 300% @ 5mA.

  • Isolation Voltage: 3750Vrms
  • Operating Temperature Range: -55°C to 110°C
  • Case/Package: 6-SO, 4 lead
  • Mounting Technology: SMD (SMT)
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 3μs
  • Rise Time: 2μs
  • Fall Time: 3μs
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
  • Status: Common-used part with high popularity and sufficient supply and demand status
  • Estimated EOL Date: 2027
