The UCC23313DWYR is a state-of-the-art isolated gate driver from Texas Instruments, designed for high-efficiency and reliability in a wide range of applications. This driver is particularly suited for driving power switches like IGBTs and MOSFETs, making it an excellent choice for advanced power conversion systems.

Key Features

• Isolation Rating: The UCC23313DWYR boasts a robust isolation rating of 5.7 kVRMS, providing secure electrical separation between the input and output, which is critical for safety in high-voltage applications.
• Peak Output Current: With a peak output current capability of ±4 A, this driver can effectively switch power transistors at high speeds, improving the performance of your power conversion system.
• Wide Operating Temperature Range: This device can operate over a broad temperature range from -40°C to +125°C, ensuring reliable performance even under extreme conditions.
• Propagation Delay: The UCC23313DWYR features a low propagation delay with a typical value of 35 ns, which is essential for maintaining timing accuracy in power switching applications.
• Fault Protection: It includes under-voltage lockout (UVLO) for both the high-side and low-side, ensuring that the device operates only when sufficient gate voltage is available, thus protecting the power switches from damage.

Applications

The UCC23313DWYR is versatile and can be used in various applications, including:

• Solar inverters
• Motor drives
• Power supplies
• Electric vehicle charging stations
• Uninterruptible power supplies (UPS)

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the UCC23313DWYR is no exception. It is built with the highest standards to ensure consistent performance and longevity, making it a reliable choice for critical power management applications.

Ordering Information

The UCC23313DWYR is available in a SOIC-16 (DW) package, providing a compact footprint for space-constrained applications. It is also available in tape and reel packaging for ease of manufacturing and assembly processes.
