Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, Flyback, Forward Converter
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 7.6 V to 30 V
Frequency - Switching 500kHz
Duty Cycle (Max) 48%
Synchronous Rectifier No
Clock Sync No
Control Features Frequency Control
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 8-SOIC
Win Source Part Number 035629-UC2845AD8TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UC2845AD8TR CAD Model

Description

The UC2845AD8TR from Texas Instruments is a high-performance current mode PWM controller that is widely utilized in switch-mode power supplies. This integrated circuit (IC) is engineered to offer precise electrical control and is suitable for a variety of applications, including power converters, motor controllers, and battery chargers.

Key Features

  • Optimized for Off-line and DC-to-DC Converters: The UC2845AD8TR is specifically designed for off-line and DC-to-DC converter applications, providing efficient power conversion.
  • Low Startup and Operating Current: This device features a low startup current of typically 0.5mA and an operating current of typically 8.5mA, making it an energy-efficient option.
  • High Current Totem Pole Output: The IC has an internally trimmed bandgap reference, and a high current totem pole output capable of driving a power MOSFET or IGBT directly, which simplifies the design of power stages.
  • Automatic Feed Forward Compensation: It includes automatic feed-forward compensation and pulse-by-pulse current limiting for enhanced performance and reliability.
  • Under-Voltage Lockout with Hysteresis: The UC2845AD8TR also features an under-voltage lockout with hysteresis to ensure stable operation under varying voltage conditions.

Package and Availability

The UC2845AD8TR is offered in a convenient 8-pin SOIC package, making it easy to integrate into a wide range of electronic assemblies. The device is available in tape and reel packaging, which facilitates automated assembly processes and is ideal for high-volume production requirements.

Applications

  • Switch-Mode Power Supplies (SMPS)
  • Power Converters
  • Motor Controllers
  • Battery Chargers
  • LED Drivers
  • DC-DC Converters

With its robust design and versatile features, the UC2845AD8TR from Texas Instruments is a reliable choice for designers and engineers looking to implement an effective power management solution in their electronic products.
