TUSB4020BIPHP Dual-Port USB 2.0 Hub Controller from Texas Instruments

The TUSB4020BIPHP is a versatile dual-port USB 2.0 hub controller developed by Texas Instruments (TI). This integrated circuit is designed to provide a high-performance and cost-effective solution for expanding USB capabilities in various electronic devices.

As a fully-compliant USB 2.0 hub, the TUSB4020BIPHP supports high-speed (480 Mbps), full-speed (12 Mbps), and low-speed (1.5 Mbps) data transfer modes, ensuring compatibility with a wide range of USB devices. It is equipped with two downstream ports that enable the connection of additional peripherals, enhancing system connectivity and user convenience.

The TUSB4020BIPHP features an advanced on-chip microprocessor, which manages the USB protocol and hub functionality without requiring external firmware. This reduces system complexity and speeds up time-to-market for products incorporating the hub controller. Additionally, its integrated PHYs (Physical Layer Transceivers) provide robust signal quality, which is essential for maintaining reliable communication over USB connections.

Key features of the TUSB4020BIPHP include:

• Support for battery charging specifications, allowing devices to charge at a faster rate.
• Over-current protection for each downstream port, enhancing system safety and reliability.
• Multi Transaction Translator (MTT) architecture, which allows each downstream port to handle high-speed data transfers independently, improving overall throughput.
• Customizable power management options that cater to various system power requirements.
• Industrial temperature range support, making it suitable for harsh environment applications.

With its compact 32-pin HTQFP (Thin Quad Flat Pack) package, the TUSB4020BIPHP is an ideal choice for space-constrained applications. Its efficient design and power-saving features make it a go-to solution for expanding USB connectivity in desktop and laptop computers, docking stations, monitors, and many other consumer electronics.

For further information, datasheets, and support, visit the Texas Instruments product page.
